TP304/316 Stainless Steel Coil Tube Price Unit

FOB Reference Price:Get Latest Price
US $3-8 / Kilograms | 10 Kilogram/Kilograms (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Standard:
ASTM, AISI, DIN, EN, GB, JIS
Place of Origin:
China (Mainland)
Brand Name:
Kingmetal
Model Number:
EL-CT
Type:
Seamless
Steel Grade:
200 Series
Application:
Heat Exchanger
Certification:
ISO, ISO,TUV,AD
Welding Line Type:
EFW
Thickness:
0.5-100mm
Outer Diameter:
6-800mm
Length:
1-30m
Supply Ability
Supply Ability:
3500 Ton/Tons per Month
Packaging & Delivery
Packaging Details
Plywood case or wooden spools
Port
China main port
Lead Time :
15-30 days after payment



ct (49)_.jpg

ct (1)_.jpg

Material

TP304/304L/304H, 316/316L, 321/321H, 317/317L, 347/347H, 309S, 310S, 2205, 2507, 904L (1.4301, 1.4306, 1.4948, 1.4401, 1.4404, 1.4571, 1.4541, 1.4833, 1.4878, 1.4550, 1.4462, 1.4438, 1.4845)

Standards: ASTM A312, A213, A269, A511, A789, A790, A376, EN 10216-5, EN 10297,DIN 17456, DIN 17458,JISG3459, JIS GS3463, GS3467, JIS G3448, GOST 9940, GOST 9941, etc.



Application:

1.Control Tubing in Oil and Gas Well

2. Instrument Tubing

3. Chemical Injection Tubing Line

4. Pre-insulated Tubing

5. Electric Heating or Steam Heating Tubing Line

6. Heater Tubing Line etc



Process: Cold drawn, Cold rolled, Precision Rolled for Seamless Pipe or Tube



Surface Bright,Polished,2B,NO.1,NO.4,HL,BA,8K,Mirror,2D,checkered,



Finish: Outside & Inside Polished

Ends: Beveled or plain end, square cut, burr free

Package:Each tube with plastic bag and caps,then in polywooden cases.





MaterialASTM A269 Chemical Composition % Max
CMnPSSiCrNiMoN BNbTi
TP3040.082.000.0450.0301.0018.0-20.08.0-11.0^^^ .^
TP304L0.0352.000.0450.0301.0018.0-20.08.0-12.0^^^^
TP3160.082.000.0450.0301.0016.0-18.010.0-14.02.00-3.00^^^
TP316L0.035 D2.000.0450.0301.0016.0-18.010.0-15.02.00-3.00^^^
TP3210.082.000.0450.0301.0017.0-19.09.0-12.0^^^5C -0.70
TP3470.082.000.0450.0301.0017.0-19.09.0-12.0  10C -1.10^
MaterialHeat treatmentTemperure F (C) Min.Hardness
BrinellRockwell
TP304Solution1900 (1040)192HBW/200HV90HRB
TP304LSolution1900 (1040)192HBW/200HV90HRB
TP316Solution1900(1040)192HBW/200HV90HRB
TP316LSolution1900(1040)192HBW/200HV90HRB
TP321Solution1900(1040) F192HBW/200HV90HRB
TP347Solution1900(1040)192HBW/200HV90HRB
OD, inchOD Tolerance inch(mm)WT Tolerance %Length Tolernace inch(mm)
+-
≤ 1 / 2± 0.005 ( 0.13 )± 151 / 8 ( 3.2 )0
> 1 / 2 ~1 1 / 2± 0.005(0.13)± 101 / 8 (3.2)0
> 1 1 / 2 ~< 3 1 / 2± 0.010(0.25)± 103 / 16 (4.8)0
> 3 1 / 2 ~< 5 1 / 2± 0.015(0.38)± 103 / 16 (4.8)0
> 5 1 / 2 ~< 8± 0.030(0.76)± 103 / 16 (4.8)0
8~< 12± 0.040(1.01)± 103 / 16 (4.8)0
12~< 14± 0.050(1.26)± 103 / 16 (4.8)0
